can engrave and cut and achieve perfect unification of two functions. The machine has stable performance,simple operation and wide processing materials, is equipped with electric lifting platform, has high speed and precision,and is the best updating choice of all walks of life....
Send InquiryQuick Details | |
Application: | Laser Engraving, Laser Engraving |
Condition: | New |
Laser Type: | CO2, CO2,CO2 sealed laser tube,water cooled |
Engraving Area: | 300*500mm |
CNC or Not: | Yes |
Cooling Mode: | Water Cooling, Water Cooling |
Applicable Material: | Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood |
Graphic Format Supported: | AI, BMP, PLT |
Place of Origin: | China (Mainland) |
Brand Name: | EO |
Model Number: | EO-3050 |
Certification: | CE, ISO, SGS |
After-sales Service Provided: | Engineers available to service machinery overseas |
Power supply: | 220V/50HZ 110V/60HZ |
Driving motor: | 2 phases stepper motor |
Laser Power: | 40W/60W |
Graphic format supported: | English 1.0*1.0mm |
Operating System Platform: | Windows XP Vista |
Min. shaping character:: | English 1.0*1.0mm |
Software supported: | CorelDraw,PhotoShop,AutoCAD,TA |
Feature:
1.Adopt high efficiency laser tube and more stable beam.
2.With the function of restoring from power off,continuation on break point.
3.Advanced DSP control system, professional motion control chip,consecutive high speed curve cutting and
the shortest path selection function improve the efficiency.
4.Red light positioning device indicates the location of laser head,eliminate the trouble about manual
positioning.
5.can engrave and cut and achieve perfect unification of two functions. The machine has stable performance,
simple operation and wide processing materials, is equipped with electric lifting platform, has high speed and
precision, and is the best updating choice of all walks of life.
Applicable Materials:
Plank, rubber, marble, bamboo products, ceramics, crystals, acryl, cloth, organic glass, leather and metal
materials.
Applicable Industries:
Advertising, artware, clothing industry, packaging and printing, mold model, embroidery and clipping, toy, etc.
Parameters: | |
Laser machine model | EO-3050 |
Laser power | 60W/80W/100W/130W/150W/metal tube |
Working area | 300*500mm |
Cutting speed | 0-25000mm/min |
Operating voltage | AC100V-220V±10%,50-60HZ |
Operating temperature/humidity | 0-45°C/5-95% |
Engraving speed | 0-60000mm/min |
Total power | <1000W |
Driving motor | Stepping motor |
Cooling method | Water cooling machine |
Auxiliary devices | Exhaust fan, smoke pipe, air pump |
Minimum shaping character | English:1*1mm |
Supported graphic format | PLT,AI,BMP,DST,DXF |
Supported software | CorelDraw,Photoshop,AutoCAD |
Control software | DSP control system |
