Oxy-hydrogen jewelry welder machine is able to separate clean soft water (H2O) into hydrogen and oxygen gases, using a small amount of electric power through a special process. These gases are then mixed and delivered for use in a wide variety of applications, such as jewelry welding, which currently use arc,laser welding.For jewelry work,it features welding fast,safety,smooth welding spot etc....
Send Inquiry| Quick Details | |
| Condition: | New |
| Place of Origin: | China (Mainland) |
| Brand Name: | EO |
| Model Number: | OH100 |
| Single Pulse Energy: | 90J |
| Pulse Width: | 0.1-20ms |
| Wavelength: | 1064 Nm |
| Focal Spot Diameter: | 0.1-2.0mm |
| Max. Output Power: | 400W |
| Dimensions: | 390*250*510mm |
| Usage: | jewelry welding |
| Power(W): | 400W |
| Certification: | CE, ISO |
| Warranty: | 1 Year |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| AC Voltage Requirement (V): | 220 /110,single phase |
| Byname: | portable oxyhydrogen jewelry welding machine in china |
| DC Voltage &Current (A): | 5V 60A |
| Max Gas Output: | 100L/h |
| Max. Working Pressure (kg/cm2): | 2 |
| Function: | conectrated oxyhydrogen flame |
| Water Feed: | manual |
| Max. Flame Modifier Consumption (L/h): | 0.05 |
| Color: | green |
| Feature: | eco-friendly,eye protection,safety |
| Technical Parameters Small Portable | ||||
| Model Number | OH100 | OH200 | OH300 | OH400 |
| AC Voltage Requirement(V) | 220/110 | |||
| Phase | single | |||
| Power Consumption(kw/h) | 0.4 | 0.8 | 1.2 | 1.4 |
| Max. Gas Output(L/h) | 100 | 200 | 300 | 400 |
| Max. Working Pressure(kg/cm2) | 2 | |||
| Max. Water Consumption(L/h) | 0.06 | 0.11 | 0.17 | 0.23 |
| Water Feed | manual | |||
| Flame Modifier Feed | manual | |||
| Dimensions-L*W*H (mm) | 390*250*510 | 450*250*510 | 590*250*510 | 710*250*510 |
| Gross Weight(kg) | 15 | 20 | 24 | 28 |
| Space Requirement(mm) | 200 | |||
What is oxy-hydrogen welding machine?
Oxy-hydrogen jewelry welder machine is able to separate clean soft water (H2O) into hydrogen and oxygen gases, using a small amount of electric power through a special process. These gases are then mixed and delivered for use in a wide variety of applications, such as jewelry welding, which currently use arc,laser welding.For jewelry work,it features welding fast,safety,smooth welding spot etc.
Our Service
Spot delivery, including delivering small batches of goods Provide wide-range and complete materials series products Cutting plates, including complex shapes of materials and special processing and disposal Cutting bars and strips Our application technology expert provide the best material and recommendation One-stop service.
