Materials: wood products, paper, cloth, leather, organic glass, acrylic, epoxy resin, unsaturated polyester resin and other non metal materials....
Send InquiryProduct Details | |
Place of Origin: | China |
Brand Name: | Leadboom |
Certification: | CE , FDA |
Model Number: | LB-MFF30 |
Detailed Product Description | |||
Laser Power: | 0~30W Serially Adjustable | Type: | LB-MFF30 |
Highest Produce Speed: | 200m/min | Mark: | Can Be Marked On Stationary Or Moving Objects |
Font: | Unlimited With The Print Range | Printing Line Numbers: | Unlimited |
Product Parameters | |||
Type | LB-MC10 | LB-MC30 | LB-MC60 |
Laser Power | 0~10W | 0~30W | 0~60W |
Laser Wavelength | 1064nm | 1064nm | 1064nm |
Pulse frequency | ≤50KHz | ≤50KHz | ≤50KHz |
Marking Area | 70x70mm 110x110mm | 110x110mm 140x140mm | 175x175mm ~ 250x250mm |
Marking Speed | ≤7000mm/s | ≤7000mm/s | ≤7000mm/s |
Min. Line Width | 0.05mm | 0.05mm | 0.05mm |
Repeated Precision | ±0.003mm | ±0.003mm | ±0.003mm |
Cooling System | Air-cooling | Air-cooling | Air-cooling |
Power Supply | 220V / 50Hz | 220V / 50Hz | 220V / 50Hz |
Power Consumption | 0.5KW | 0.8KW | 2KW |
Dimension | 820x620x1360mm | 860x620x1360mm | 1200x620x1500mm |
Application Filed
A. Materials: wood products, paper, cloth, leather, organic glass, acrylic, epoxy resin, unsaturated polyester resin and other non metal materials.
B. Industry: craft gift,furniture, leather and cloth, advertising signs, model products, food packaging,electronic components, pharmaceutical packaging, printing plate, nameplate, case and so on.
Our Service
Spot delivery, including delivering small batches of goods
Provide wide-range and complete materials series products
Cutting plates, including complex shapes of materials and special processing and disposal
Cutting bars and strips
Our application technology expert provide the best material and recommendation
One-stop service
