CNC Wood Laser Cutting and Engraving Machine

Product Parameters

Product Features

 Automatic Lubrication System

Electrical lubrication is a kind of gear pump with rational construction, great performance and comprehensive functions.

By connection with program control system in the main machine, the lubrication system could oversee oil level within tank as well as oil transmission pressure and set lubrication periodicity, which will effectively prevent rust within lubrication system to ensure cutting accuracy

 Japan NSK Bearings

These bearing housings have square flange which can be easily attached to a machine with four bolts.

With its simple mounting face, this bearing unit is widely used

 Japan SMC pneumatic components

Stepless control of air pressure proportional to an electrical signal.

Serial communications specifications.

Compact/lightweight (Integrated communication parts).

 France Schneider Electronic

Circuit protection against short-circuit currents,

Circuit protection against overload currents,

Breaking and industrial disconnection as per standards IEC/EN 60947-2.

Overvoltage resistance,

High performance limitation,

To fast closing independent of the speed of actuation of the toggle

 Fagor Servo Motor

Wide range of rated power from 0.22 to 18.8 kW and rated speed from 2000 rev/min to 6000 rev/min.

Uniform output torque.

High torque/volume ratio. High reliability.

Low maintenance

 France MOTOREDUCER

Satellite gears are double-supported on hardened and ground shafts with full-complement needle bearings increasing torsional stiffness.

Backlash ≤ 3 arcmin.

Standard operating temperature range is -15℃ to 45℃.

Protection rated IP 65 standard

 Switzerland RAYTOOLS Laser Head

Rotary Knob type focus point adjustment for fine and flexible adjustment. Adjustable range: 20mm, accuracy: 0.05mm.

Drawer type mirror seat to make protect glass replacing faster and easier.

Both collimating lens and focal lens could apply compound lens for optimal optical quality and cutting result.

 WIFI Wireless Control

For speedy service, we add WIFI function for our technician to operate troubleshooting and adjust parameters remotely.

Check laser source parameters to analyze failure causes.

Check cutting parameters to analyze and adjust new parameters

Product Advantages

 Excellent path quality: Smaller laser dot and high work efficiency, high quality.

 High cutting speed: cutting speed is 2-3 times than same power CO2 laser cutting machine.

 Stable running: adopt top world import fiber lasers, stable performance, key parts can reach 100,000 hours;

 High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine have three times photoelectric conversion efficiency.

 Low cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.

 Low maintenance: fiber line transmission no need reflect lens, save maintenance cost;

 Easy operations: fiber line transmission, no adjustment of optical path.

More

Our Services:

Pre-sale services: enthusiasm

We provide you with the process plan, process flow design and manufacturer equipment according to your special demand.

Sale services: servant

Send technicians to the job site for guiding the installation and adjustment of CNC Wood Laser Cutting And Engraving Machine, training operators and finishing the check and accept together with you.

After-sale services: faithfulness

To establish long term friendship, we will regularly pay return visit to customers.
